Aruba AP-303 (US) Dual 2×2:2 MU-MIMO Radio Internal Antennas Unified Campus AP

(JZ321A)

Categories: Networking, Aruba 303 Series Campus Access Points, HP Switches, Aruba

The Aruba 303 Series Campus Access Points delivers an affordable high performance 802.11ac with MU-MIMO (Wave 2) for medium density enterprise environments. With the integrated Bluetooth Low Energy (BLE) and supporting 802.3af power, the Aruba 303 enables enterprises to improve their work efficiency and productivity with low TCO. The compact Aruba 303 Series Campus Access Point delivers a maximum concurrent data rate of 867 Mbps in the 5 GHz band and 300 Mbps in the 2.4 GHz band (for an aggregate peak data rate of 1.2 Gbps). Featuring 2×2:2SS, it is designed for device density environments, such as schools, retail branches, warehouses, hotels and enterprise offices, where the environment is cost sensitive.

What’s New

The Aruba AP-303P models allow you to daisy-chain your wired network to connect and power any network device (IP camera, IOT gateway, or a second access point) to the E1 Ethernet port of the AP-303P.
Simplify and cost-reduce the installation of multiple devices by sharing switch ports and cabling.
AP-303P models support Zigbee 802.15.4 radio to provide connectivity for IoT devices.
2:2:2SS SU-MIMO and MU-MIMO operation, channel width up to 80 MHz.
Unified access points supporting ArubaOS and InstantOS modes.

Product Specifications

Certifications CB Scheme Safety, cTUVus UL2043 plenum rating Wi-Fi Alliance certified 802.11a/b/g/n Wi-Fi CERTIFIED ac (with wave 2 features)Input Voltage 48 VDCRegulatory FCC/ISED CE Marked RED Directive 2014/53/EU EMC Directive 2014/30/EU Low Voltage Directive 2014/35/EU UL/IEC/EN 60950 EN 60601-1-1, EN60601-1-2Wi-Fi Antenna Two internal vertically polarized, dual-band downtilt, omni-directional antennas.Connectivity 10/100/1000BASE-TExternal I/O Ports 1 RJ45 1 micro-USBMounting Ceiling, wall, wiring box, using range of mounts and kits. Basic mounts ship with product.Power Consumption Description 10.1W PoE or 8.8W DC, maximumRadio Coverage Indoor, dual radio, 5 GHz 802.11ac 2×2 MIMO and 2.4 GHz 802.11n 2×2 MIMO.Warranty Standard Statement Limited lifetime warranty: for details, see http://www.arubanetworks.com/support-services/product-warranties/#HardwareLLWProduct Differentiator (long) The affordable mid-range Aruba 303 Series campus access point delivers high performance 802.11ac with MU-MIMO (wave 2) for medium density enterprise environments. With the integrated BLE and supporting 802.3af power, the Aruba 303 Series AP enables enterprises to improve their work efficiency and productivity with the lowest TCO. This model is for use in United States regulatory domains.Weight (imperial) 9.2 ozWeight (metric) 260 gProduct Dimensions (imperial) 1.4 x 5.9 x 5.9 inProduct Dimensions (metric) 35 x 150 x 150 mm
