Home » Products » Servers » HP ProLiant » Rackmount Servers » DL325 Gen10 » HPE ProLiant DL325 Gen10 AMD EPYC 7351P 16GB RAM 8SFF PS Performance Server

HPE ProLiant DL325 Gen10 AMD EPYC 7351P 16GB RAM 8SFF PS Performance Server

(5171474)

Categories: Servers, HP ProLiant, Rackmount Servers, DL325 Gen10

Do you need a dense platform with built-in security and flexibility that addresses key applications such as virtualization and software-defined storage (SDS)? The HPE ProLiant DL325 Gen10 Server is a secure and versatile single socket (1P) 1U AMD EPYC-based platform offers an exceptional balance of processor, memory and I/O for virtualization and data intensive workloads. With up to 32 cores, up to 16 DIMMs, 2 TB memory capacity and support for up to 10 NVMe drives, this server delivers 2P performance with 1P economics.

Product Specifications

Chassis
Form Factor :Rack-mountable
Manufacturer Form Factor :Rack-mountable
Server Storage Bays :Hot-swap
Server Swappable Drive Form Factor :2.5″
Server Swappable Drive Form Factor (metric) :6.4 cm
Server Swappable Drive Interface :SAS
Hot-Swap Bays Qty :8
Built-in Devices :Battery, LED panel

Processor
Type :EPYC
Number of Cores :16-core
Processor Number :7351P
Installed Qty :1
Max Supported Qty :1
Server Scalability :1-way
Upgradability :Upgradable
Manufacturer :AMD
Clock Speed :2.4 GHZ
Max Turbo Speed :2.9 GHZ

Cache Memory
Type :L3 cache
Per Processor Size :64 megabyte, 64 megabyte
Installed Size :64 megabyte

RAM
Form Factor :DIMM 288-pin
Technology :DDR4 SDRAM
Installed Size :16 GB
Max Supported Size :2 TB
Configuration Features :2 x 8 GB
Slots Qty :16
Empty Slots :14
Memory Speed :2666 megahertz
Rated Memory Speed :2666 megahertz
Memory Specification Compliance :PC4-20800
Features :HPE SmartMemory, Registered

Type :RAID
Bus Type :PCI Express 3.0 x8
Interface Type :Serial ATA-600 / SAS 3.0
Storage Controller Name :HPE Smart Array E208i-a
Channel Qty :8
Installed Qty :1
RAID Level :RAID 0, RAID 1, RAID 10, RAID 5

Networking
Ethernet Controller(s) :HPE 331i
Remote Management Controller :Integrated Lights-Out 5
Data Link Protocol :Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Ports :4 x Gigabit Ethernet
Remote Management Protocol :IPMI 2.0, SMASH CLP, SNMP 3
Features :PXE support, Wake on LAN (WoL)

Expansion Bays
Bays :1 (total) / 1 (free) x external, 8 (total) / 8 (free) x hot-swap 2.5″ SFF

Expansion Slots
Slots :1 (total) / 1 (free) x FlexibleLOM – three-quarter-length, full-height (low-profile), 1 (total) / 1 (free) x microSD Card (internal), 1 (total) / 1 (free) x PCIe 3.0 x16 – full-height, 1 (total) / 1 (free) x PCIe 3.0 x8 (low-profile)

Interface Provided
Interfaces :1 x HP iLO (1 in front), 1 x HP iLO (1 rear), 1 x HPE iLO (1 in front), 1 x HPE iLO (1 rear), 1 x VGA (1 rear), 4 x LAN (Gigabit Ethernet) (4 rear), 5 x USB 3.0 (1 front, 2 rear, 2 internal)

Power Device
Type :Power supply – hot-plug
Power Redundancy :Optional
Power Redundancy Scheme :1+1 (with optional power supply)
Installed Qty :1
Max Supported Qty :2
Power Provided :500 watt
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
