HPE ProLiant DL325 Gen11 Smart Choice – EPYC 9354P 3.25 GHz – 256GB – SSD 2 x 1.92 TB – 2 x 800W – rack server

(P72990-005)

Categories: Servers, HP ProLiant, Rackmount Servers, DL325 Gen11

Are you looking for a scalable, low-cost performance server solution for your virtualized and software-defined compute workloads? The HPE ProLiant DL325 Gen11 server is a low-cost 1U 1P solution that delivers exceptional value balancing compute, memory and network bandwidth at 1P economics. Powered by 4th Generation AMD EPYC Processors with up to 128 cores, increased memory bandwidth (up to 3 TB), high-speed PCIe Gen5 I/O and EDSFF storage, and supporting up to two GPUs at the front, this server is a superb low-cost, 1U 1P, performance solution for your virtualized workloads. The silicon root of trust anchors the server firmware, creating a fingerprint for the AMD Secure Processor that must be matched exactly before the server will boot. The HPE ProLiant DL325 Gen11 server is an excellent choice for virtualized workloads such as software-defined compute, CDN, VDI, and secure edge apps that require balancing processor, memory, and network bandwidth.

Quick tech specs

Server
1-way
RAM 64 GB
hot-swap 2.5″ bay(s)
NVMe
monitor: none
rack-mountable 1U
1 x EPYC 9354P / up to 3.8 GHz
SATA/SAS/NVMe
SSD 2 x 1.92 TB
10 Gigabit Ethernet, 25 Gigabit Ethernet
Smart Choice

Product Specifications

BrandHPE

Product LineHPE ProLiant

ModelDL325 Gen11

ManufacturerHPE Smart Buy Express

Bus TypeOpen Compute Project mezzanine (OCP)

Clock Speed3.25 GHZ

Cores32-core

Max Turbo Speed3.8 GHZ

Processor BrandAMD

Processor Number9354P

Processor TypeEPYC

Processors Installed1

Server Scalability1-way

Total Processor Supported1

UpgradabilityUpgradable

Available Memory Slots11

Cache MemoryL3 cache

Cache Memory Installed256 megabyte

Configuration Features1 x 64 GB

Data Integrity CheckAdvanced ECC

FeaturesHPE SmartMemory, Online Spare Memory, Registered

Max Memory Supported3 TB

Memory Slots12

Memory Speed4800 megahertz

Memory TechnologyDDR5 SDRAM

RAM Installed64 GB

Rated Memory Speed4800 megahertz

Buffer Size4 GB

Channel Quantity8

Drive TypeNo optical drive

Hard Drive Capacity1.92 TB

Hard Drive FeaturesNVM Express (NVMe)

Installed Quantity2

Optical Drive TypeNo optical drive, None

Optical Drive Type (2nd)None

RAID LevelsRAID 0, RAID 1, RAID 10, RAID 5, RAID 50, RAID 6, RAID 60

Storage (2nd)None

Storage (3rd)None

Storage (4th)None

Storage Controller (2nd)None

Storage Controller NameHPE MR408i-o Gen11 SPDM

Storage Controller TypeRAID

TypeNone

Hard Drive Interface TypeSSD

Data Link Protocols10 Gigabit Ethernet, 25 Gigabit Ethernet

Ethernet ControllersBroadcom BCM57414

Ethernet Ports2 x 10/25 Gigabit Ethernet SFP28

FeaturesPXE support, Wake On LAN (WOL)

Host InterfaceOpen Compute Project mezzanine (OCP) 3.0

Remote ManagementIPMI 2.0, SNMP 3

Remote Management ControllerIntegrated Lights-Out 6

Expansion Bays8 (total) / 8 (free) x hot-swap 2.5″ SFF

Slots1 (total) / 1 (free) x PCIe 5.0 x16 – full-length, full-height (x16 mode)

Interface Provided1 x HPE iLO – RJ-45, 1 x HPE iLO (1 in front) (service port), 1 x VGA, 2 x LAN (10/25 Gigabit Ethernet) – SFP28, 5 x USB 3.2 Gen 1 (1 front, 2 rear, 2 internal)

Display TechnologyNone.

Video InterfacesVGA

Installed Size16 megabyte

Frequency50/60 hertz

Power Device TypePower supply – hot-plug

Power Provided800 watt

Power Supplies Installed2

Power Supplies Supported2

Redundant Power SupplyYes

Redundant Power Supply Supported1+1

Required VoltageAC 100-120/200-240 volt

80 PLUS Certification80 PLUS Platinum

OS CertifiedMicrosoft Windows Server 2019, Microsoft Windows Server 2022, Red Hat Enterprise Linux 8.6, Red Hat Enterprise Linux 9.0, SUSE Linux Enterprise Server 15 SP4, VMware vSphere 7.0 (ESXi) Update 3, VMware vSphere 8.0 (ESXi), VMware vSphere 8.0 (ESXi) Update 1, VMware vSphere 8.0 (ESXi) Update 2

Built-in DevicesLED panel

Embedded SecurityTrusted Platform Module (TPM) Security Chip

Form FactorRack-mountable

Form Factor (RAM)DIMM 288-pin

Storage Controller InterfaceSerial ATA-600 / SAS 3.0 / PCI Express (NVMe)

Max Operating Temperature95 degree Fahrenheit

Min Operating Temperature50 degree Fahrenheit

Operating Humidity8 – 90% RH (non-condensing)

Controllers Included1

CountryCanada, United States

Printer Product TypeNone

Hot-Swap Bays8

Manufacturer Form FactorRack-mountable

Packaged Quantity1

Product TypeServer

Server Storage BaysHot-swap

Server Swappable Drive Form Factor2.5″

Server Swappable Drive Form Factor (metric)6.4 cm

Server Swappable Drive InterfaceSATA/SAS/NVMe

Included Accessories7 x performance fans, HPE Easy Install Rail 2 Kit, Performance heatsink

Height1.7 inch

Height (Rack Units)1

Weight27.69 lbs

Width17.1 inch

Depth25.6 inch

Color CategoryBlack, Silver

Compliant StandardsACPI 6.1, Active Directory v1.0, AES, APML 1.0, ASHRAE Class A3, ASHRAE Class A4, FIPS 140-2, IPv6 Ready, PCI DSS, Redfish API, SMBIOS 3.1, TLS v1.2, Triple DES, UEFI 2.7, UEFI Class 3, WEEE 2002/95/EC

ENERGY STAR CertifiedYes

Energy Star Version4.0

TCO CertifiedNo

On-Site WarrantyOn-site

Service & Support DetailsLimited warranty – parts and labor – 3 years – on-site – response time: next business day

Limited Warranty3 Year
