The HPE ProLiant DL380 Gen10 server delivers better security, performance and expandability. The HPE ProLiant DL380 Gen10 server is securely designed to reduce costs and complexity. Run everything from the most basic to mission-critical applications and deploy with confidence.
* Manufacturer’s Suggested Retail Price
Chassis
Form Factor :Rack-mountable
Manufacturer Form Factor :Rack-mountable
Server Storage Bays :Hot-swap
Server Swappable Drive Form Factor :2.5″
Server Swappable Drive Form Factor (metric) :6.4 cm
Server Swappable Drive Interface :SATA
Hot-Swap Bays Qty :8
Processor
Type :Xeon Gold
Number of Cores :Quad-Core
Processor Number :5222
Installed Qty :1
Max Supported Qty :2
Server Scalability :2-way
Upgradability :Upgradable
Manufacturer :Intel
Clock Speed :3.8 GHZ
Max Turbo Speed :3.9 GHZ
Processor Main Features :Hyper-Threading Technology, Intel Turbo Boost Technology 2
Cache Memory
Type :L3 cache
Installed Size :16.5 megabyte
RAM
Form Factor :DIMM 288-pin
Technology :DDR4 SDRAM
Installed Size :32 GB
Max Supported Size :1.5 TB
Configuration Features :1 x 32 GB
Data Integrity Check :Advanced ECC
Slots Qty :24
Empty Slots :23
Memory Speed :2933 megahertz
Rated Memory Speed :2933 megahertz
Features :Dual rank, HPE SmartMemory, Registered, Slots 13 – 24 are available in two-processor configuration only
Type :Serial ATA
Interface Type :Serial ATA-600
Storage Controller Name :HPE Smart Array S100i SR Software RAID
Channel Qty :14
Installed Qty :1
Networking
Remote Management Controller :Integrated Lights-Out 5
Data Link Protocol :10 Gigabit Ethernet
Ethernet Ports :2 x 10 Gigabit Ethernet
Features :PXE support, Wake on LAN (WoL)
Expansion Bays
Bays :8 (total) / 8 (free) x hot-swap 2.5″ SFF
Expansion Slots
Slots :1 (total) / 0 (free) x FlexibleLOM, 1 (total) / 1 (free) x microSD Card (internal), 1 (total) / 1 (free) x PCIe 3.0 x16 – full-length, full-height, 1 (total) / 1 (free) x PCIe 3.0 x8 – full-length, full-height, 1 (total) / 1 (free) x PCIe 3.0 x8 – half-length, full-height
Interface Provided
Interfaces :1 x HPE iLO, 1 x HPE iLO (service port), 1 x VGA, 2 x LAN (10Gigabit Ethernet) (SFP+), 3 x USB 3.0 (1 front, 2 rear)
Power Device
Type :Power supply – hot-plug
Power Redundancy :Optional
Power Redundancy Scheme :1+1 (with optional power supply)
Installed Qty :1
Max Supported Qty :2
Power Provided :800 watt
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
Service & Support Details
Service & Support :Limited warranty – parts and labor – 3 years – on-site
