Building on HPE ProLiant as the intelligent foundation for hybrid cloud, the HPE ProLiant DL385 Gen10 Plus server offers a powerful processor. With 32 DIMMs for memory up to 3200 MHz, the HPE ProLiant DL385 Gen10 Plus server delivers low cost virtual machines (VMs) with unprecedented security. Equipped with PCIe Gen4 capabilities, HPE ProLiant DL385 Gen10 Plus offers improved data transfer rates and higher networking speeds. Combined with a better balance of processor cores, memory and I/O, HPE ProLiant DL385 Gen10 Plus is an ideal choice for virtualization, and memory-intensive and HPC workloads.
* Manufacturer’s Suggested Retail Price
Chassis
Form Factor :Rack-mountable
Manufacturer Form Factor :Rack-mountable
Server Storage Bays :Hot-swap
Server Swappable Drive Form Factor :2.5″
Server Swappable Drive Form Factor (metric) :6.4 cm
Server Swappable Drive Interface :SAS
Hot-Swap Bays Qty :24
Built-in Devices :LED panel
Processor
Type :EPYC
Number of Cores :64-core
Processor Number :7702
Installed Qty :1
Max Supported Qty :2
Server Scalability :2-way
Manufacturer :AMD
Clock Speed :2 GHZ
Cache Memory
Per Processor Size :256 megabyte, 256 megabyte
Installed Size :256 megabyte
RAM
Technology :DDR4 SDRAM
Installed Size :32 GB
Configuration Features :2 x 16 GB
Rated Memory Speed :3200 megahertz
Features :Registered
Type :RAID
Bus Type :PCI Express 3.0 x8
Interface Type :Serial ATA-600 / SAS 3.0
Storage Controller Name :HPE Smart Array P408i-a
Channel Qty :8
Installed Qty :1
Buffer Size :2 GB, 2 GB
RAID Level :10ADM, 1ADM, RAID 0, RAID 1, RAID 10, RAID 5, RAID 50, RAID 6, RAID 60
Networking
Data Link Protocol :10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Ports :2 x 10 Gigabit Ethernet
Expansion Bays
Bays :24 (total) / 24 (free) x hot-swap 2.5″ SFF
Expansion Slots
Slots :1 (total) / 1 (free) x PCIe 3.0 x16, 2 (total) / 2 (free) x PCIe 3.0 x8
Interface Provided
Interfaces :1 x HP iLO, 1 x HPE iLO, 2 x LAN (10Gigabit Ethernet)
Power Device
Type :Power supply – hot-plug
Power Redundancy :Optional
Power Redundancy Scheme :1+1 (with optional power supply)
Installed Qty :1
Max Supported Qty :2
Power Provided :800 watt
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
Service & Support Details
Service & Support :Limited warranty – parts and labor – 3 years – on-site – response time: next business day
