HPE ProLiant DL580 Gen10 Base – rack-mountable – Xeon Gold 6230 2.1 GHz – 2

(5531840)

Categories: Servers, HP ProLiant, Rackmount Servers, DL580 Gen10

Looking for a highly scalable, workhorse server to address your database, storage, and graphics intensive applications? The HPE ProLiant DL580 Gen10 server is a secure, highly expandable, 4P server with high-performance, scalability and availability in a 4U chassis. The HPE ProLiant DL580 Gen10 server delivers greater processing power and is the ideal server for business-critical workloads and general 4P data-intensive applications where the right performance is paramount.

Product Specifications

Chassis Form Factor :Rack-mountable Manufacturer Form Factor :Rack-mountable Server Storage Bays :Hot-swap Server Swappable Drive Form Factor :2.5″ Server Swappable Drive Form Factor (metric) :6.4 cm Server Swappable Drive Interface :SAS Hot-Swap Bays Qty :8 Processor Type :Xeon Gold Number of Cores :18-core, 20-core Processor Number :6230 Installed Qty :4 Max Supported Qty :4 Server Scalability :4-way Upgradability :Upgradable Manufacturer :Intel Clock Speed :2.1 GHZ Max Turbo Speed :3.9 GHZ Processor Main Features :Hyper-Threading Technology, Intel Turbo Boost Technology 2

Cache Memory Per Processor Size :27.5 megabyte, 27.5 megabyte Installed Size :110 megabyte RAM Form Factor :DIMM 288-pin Technology :DDR4 SDRAM Installed Size :256 GB Max Supported Size :1.5 TB Configuration Features :8 x 32 GB Data Integrity Check :ECC Slots Qty :48 Empty Slots :40 Memory Speed :2933 megahertz Rated Memory Speed :2933 megahertz Memory Specification Compliance :PC4-23466 Features :HPE SmartMemory, Registered

Type :RAID Bus Type :PCI Express 3.0 x8 Interface Type :Serial ATA-600 / SAS 3.0 Storage Controller Name :Smart Array P408i-p SR Installed Qty :1

Networking Ethernet Controller(s) :HPE 535FLR-T Interface (Bus) Type :PCI Express 2.0 x4 Data Link Protocol :10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet Ethernet Ports :2 x 10 Gigabit Ethernet Features :ACPI support, PXE support, Wake on LAN (WoL) Compliant Standards :IEEE 802.1as, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3az, IEEE 802.3u, IEEE 802.3x Expansion Bays Bays :8 (total) / 8 (free) x hot-swap 2.5″ SFF Expansion Slots Slots :1 (total) / 1 (free) x FlexibleLOM, 1 (total) / 1 (free) x microSD Card, 16 (total) / 16 (free) x PCIe 3.0 x16 Interface Provided Interfaces :1 x HP iLO – RJ-45, 1 x HP iLO (1 in front), 1 x HPE iLO – RJ-45, 1 x HPE iLO (1 in front), 1 x serial, 1 x VGA, 2 x LAN (10Gigabit Ethernet), 2 x USB 2.0, 5 x USB 3.0 (1 front, 2 rear, 2 internal)

Power Device Type :Power supply – hot-plug Power Redundancy :Yes Installed Qty :4 Max Supported Qty :4 Power Provided :1600 watt Nominal Voltage :AC 120/230 V Frequency Required :50/60 hertz 80 PLUS Certification :80 PLUS Platinum

Service & Support Details Service & Support :Limited warranty – parts and labor – 3 years – on-site
