HPE ProLiant ML30 Gen11 Performance – tower Xeon E-2436 2.9 GHz – 16 GB – no HDD

(P65096-001)

Categories: Servers, HP ProLiant, Tower Servers, ML30 Gen11

Do you need a reliable enterprise-class tower server that can easily meet your budget? The HPE ProLiant ML30 Gen11 Plus server is a powerful yet affordable tower server designed for small offices, remote and branch offices to run on-premises and hybrid cloud solutions, delivering enterprise-class performance, security, reliability, and expandability at a low cost. Hewlett Packard Enterprise builds security right into the server with HPE iLO silicon root of trust. A redundant power supply option and up to 4 LFF or 8 SFF hot-plug HDDs provide availability and flexibility. The enhanced expansion capability, now including PCIe Gen5, allows you to upgrade with serial attached SCSI (SAS) controllers or networking cards as your business grows, which can give you an extra edge. Power your business now with an HPE ProLiant ML30 Gen11 server.

Quick tech specs

Server
1-way
RAM 16 GB
hot-swap 2.5″ bay(s)
Gigabit Ethernet
tower 4U
1 x Xeon E-2436 / up to 5 GHz
SATA
no HDD
monitor: none

Product Specifications

BrandHPE

Product LineHPE ProLiant

ModelML30 Gen11 Performance

ManufacturerHewlett-Packard

Clock Speed2.9 GHZ

Cores6-core

Max Turbo Speed5 GHZ

Processor BrandIntel

Processor Main FeaturesHyper-Threading Technology, Intel Smart Cache, Intel Turbo Boost Technology 2

Processor NumberE-2436

Processor TypeXeon

Processors Installed1

Server Scalability1-way

Total Processor Supported1

UpgradabilityUpgradable

Available Memory Slots3

Cache Memory Installed18 megabyte

Configuration Features1 x 16 GB

Data Integrity CheckECC

FeaturesHPE Standard Memory, Unbuffered

Max Memory Supported128 GB

Memory Slots4

Memory TechnologyDDR5 SDRAM

RAM Installed16 GB

Rated Memory Speed4800 megahertz

Drive TypeNo optical drive

Optical Drive TypeNo optical drive, None

Optical Drive Type (2nd)None

RAID LevelsRAID 0, RAID 1, RAID 10, RAID 5

Storage (2nd)None

Storage (3rd)None

Storage (4th)None

Storage Controller (2nd)None

Storage Controller NameIntel VROC SATA Software RAID

Storage Controller TypeSerial ATA

TypeNone

Hard Drive Interface TypeNo HDD

Data Link ProtocolsEthernet, Fast Ethernet, Gigabit Ethernet

Ethernet ControllersBroadcom BCM5719

Ethernet Ports4 x Gigabit Ethernet

FeaturesPXE support, Wake On LAN (WOL)

Remote Management ControllerIntegrated Lights-Out 6

Expansion Bays8 (total) / 8 (free) x hot-swap 2.5″ SFF

Slots1 (total) / 1 (free) x M.2 Card, 1 (total) / 1 (free) x PCIe 4.0 x8 – full-length, full-height (x4 mode, processor), 1 (total) / 1 (free) x PCIe 5.0 x16 – full-length, full-height (x16 mode, processor), 2 (total) / 2 (free) x PCIe 4.0 x8 – half-length, full-height (x4 mode, PCH)

Interface Provided1 x DisplayPort, 1 x HPE iLO – Type A (1 front) (service port), 1 x LAN (Gigabit Ethernet) / HPE iLO – RJ-45 (1 rear), 1 x VGA, 3 x LAN (Gigabit Ethernet) – RJ-45 (3 rear), 5 x USB 3.2 Gen 1 (1 front, 4 rear)

Display TechnologyNone.

Video InterfacesDisplayPort, VGA

Audio Input TypeNone

Installed Size16 megabyte

Power Device TypePower supply – hot-plug

Power Provided500 watt

Power Supplies Installed1

Power Supplies Supported2

Redundant Power SupplyOptional

Redundant Power Supply Supported1+1 (with optional power supply)

80 PLUS Certification80 PLUS Platinum

Software TypeHPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)

Built-in DevicesLED panel

Chipset TypeIntel C262

Embedded SecurityTrusted Platform Module (TPM) Security Chip

Form FactorTower

Form Factor (RAM)DIMM 288-pin

Storage Controller InterfaceSerial ATA-600

Max Operating Temperature95 degree Fahrenheit

Min Operating Temperature50 degree Fahrenheit

Operating Humidity8 – 90% RH (non-condensing)

Sound Emission24 dBA

Controllers Included1

CountryNorth America

Printer Product TypeNone

Hot-Swap Bays8

Manufacturer Form FactorTower

Packaged Quantity1

Product TypeServer

Security Slot TypeKensington security slot

Server Storage BaysHot-swap

Server Swappable Drive Form Factor2.5″

Server Swappable Drive Form Factor (metric)6.4 cm

Server Swappable Drive InterfaceSATA

Theft ProtectionPadlock eye, Security lock slot (cable lock sold separately)

Included AccessoriesNon-hot plug non-redundant system fan

Height14.5 inch

Height (Rack Units)4

Weight22.49 lbs

Width6.9 inch

Depth18.7 inch

Color CategoryBlack

Compliant StandardsACPI 6.3, Active Directory v1.0, AES, ASHRAE Class A3, ASHRAE Class A4, EU Lot 9, Redfish API, TLS v1.2, Triple DES, UEFI 2.9

ENERGY STAR CertifiedYes

Energy Star Version4.0

TCO CertifiedNo

On-Site WarrantyOn-site

On-Site Warranty Comments1st year only

Service & Support DetailsLimited warranty – parts – 3 years – on-site – response time: next business day, Limited warranty – parts and labor – 1 year – on-site – response time: next business day

Limited Warranty3 Year
