PowerEdge XE7740 empowers enterprise AI insights with flexible air-cooled PCIe GPU configurations for inferencing and model fine-tuning.
* Manufacturer’s Suggested Retail Price
Two Intel® Xeon® 6 series processors with up to 86 cores per processor
32 DDR5 DIMM slots, supports RDIMM 3 TB max, speeds up to 6400 MT/s
Supports unregistered ECC DDR5 DIMMs only
Note: Future releases will support 128GB DIMMs, increasing the maximum capacity to 4TB
8x PCIe Gen 5 x16 DW-FHFL up to 600W or
16x PCIe Gen 5 x16 SW-FHFL up to 75W
Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS): HWRAID 1, 2 x M.2 NVMe SSDs
Up to 8 x EDSFF E3.S Gen5 NVMe (SSD) max 122.88 TB
3200W Titanium 200-240 V AC or 240 V DC, hot swap redundant
Multi capacity for 3200W PSU:3200W for 220.1-240 V AC or 2900W for 200-220 V AC
Air cooling
Up to four sets of high performance (HPR) platinum grade fans (dual fan module) installed in mid tray
Up to twelve high performance (HPR) platinum grade fans installed on the front of the system
All are hot swap fans
Height – 174.3 mm (6.86 inches)
Width – 482 mm (18.98 inches)
Depth – 899.56 mm (35.42 inches) with bezel
886.73 mm (34.91 inches) without bezel
4U rack server
iDRAC10
iDRAC Direct*
iDRAC RESTful API with Redfish
iDRAC Service Module (iSM)*
RACADM CLI
OpenManage Enterprise (OME)*
OME Power Manager*
OME Services*
OME Update Manager*
OME APEX AIOps Observability*
OME Integration for VMware vCenter (with VMware Aria
Operations)*
Optional security bezel
IPMI
Enterprise Catalogs / Linux Repositories
RedHat Ansible Collections*
Chassis Intrusion Detection
Cryptographically signed firmware
Data at Rest Encryption (SEDs with local or external key
mgmt)*
Secure Boot
Secured Component Verification (Hardware integrity check)
Secure Erase
Silicon Root of Trust
System Lockdown (requires iDRAC10 Enterprise or Datacenter)
TPM 2.0 FIPS, CC-TCG certified
Front Ports:
1 x USB 2.0 Type-A (optional)
1 x Mini-Display port (optional)
1 x USB 2.0 Type-C dual mode (Host/iDRAC Direct port)
Rear Ports on DC-SCM:
1 x Dedicated iDRAC/BMC Direct Ethernet port
2 x USB 3.1 Type A port
1 x VGA
Up to 8 PCIe Gen5 x16 SW-FHHL cards, each up to 150W
1 x OCP NIC card 3.0 (optional)
Canonical Ubuntu Server LTS
RedHat Enterprise Linux*
SUSE Linux Enterprise Server*
VMware ESXi*
For specifications and interoperability details, see
Dell.com/OSsupport.
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. For more information, visit
Dell.com/OEM.
