Rapidly develop, train and deploy large machine learning models with this high-performance application server made for artificial intelligence (AI), machine learning and deep learning. Dell’s PowerEdge XE9680 delivers the industry’s best AI performance.*
* Manufacturer’s Suggested Retail Price
Two 5th Generation Intel Xeon Scalable processors with up to 64 cores per processor
Two 4th Generation Intel Xeon Scalable processors with up to 56 cores per processor
32 DDR5 DIMM slots, supports RDIMM 4 TB max,
Speeds up to 5600 MT/s on the 5th Generation Intel Xeon Scalable processors
Speeds up to 4800 MT/s on the 4th Generation Intel Xeon Scalable processors
Supports registered ECC DDR5 DIMMs only
8 NVIDIA HGX H100 80GB 700W SXM5 GPUs, fully interconnected with NVIDIA NVLink technology or
8 NVIDIA HGX H200 141GB 700W SXM5 GPUs, fully interconnected with NVIDIA NVLink technology or
8 NVIDIA HGX H20 96GB 500W SXM5 GPUs, fully interconnected with NVIDIA NVLink technology or
8 AMD Instinct MI300X 192GB 750W OAM accelerator with AMD Infinity Fabric connectivity or
8 Intel Gaudi 3 128GB 900W OAM accelerator with embedded RoCE ports for ethernet connectivity
Internal Controllers (RAID): PERC H965i (Not supported with Intel Gaudi3)
Internal boot: Boot Optimized Storage Subsystem (NVMe BOSS-N1): HWRAID 1, 2 x M.2 SSDs
Software RAID: S160
Up to 8 x 2.5-inch NVMe/SAS/SATA SSD drives max 122.88 TB
Up to 16 x E3.S NVMe direct drives max 122.88 TB
Note: Only 8 x 2.5-inch NVMe SSD drives are supported with Intel Gaudi3.
3200W Titanium 277 VAC or 260-400 VDC, hot swap redundant (only available in the US & Canada)
3000W Titanium 200-240 VAC or 240 VDC, (Multi-rated, available only with Intel Gaudi 3)
2800W Titanium 200-240 VAC or 240 VDC, hot swap redundant
Air cooling
Intel® C741 chipset
Up to 10 x16 Gen5 (x16 PCIe) full-height, half-length (8 PCIe slots with Intel Gaudi 3)
2 x 1 GbE
6 x 800 Gb (available only with Intel Gaudi 3)
1 x OCP 3.0 (x8 PCIe lanes)
Up to six high performance (HPR) gold grade fans installed in mid tray
Up to ten high performance (HPR) gold grade fans installed on the rear of the system (up to 12 fans with Intel Gaudi 3)
Height — 263.2 mm (10.36 inches)
Width — 482.0 mm (18.97 inches)
Depth — 1008.77 mm (39.71 inches) with bezel
— 995 mm (39.17 inches) without bezel
Weight — up to 114.05 kg (251.44 pounds)
6U rack server
iDRAC9
iDRAC Direct
iDRAC RESTful API with Redfish
iDRAC Service Module
Optional LCD bezel or security bezel
CloudIQ for PowerEdge plug in
OpenManage Enterprise
OpenManage Service plugin
OpenManage Power Manager plugin
OpenManage Update Manager plugin
BMC Truesight
OpenManage Integration with ServiceNow
Red Hat Ansible Modules
Terraform Providers
Cryptographically signed firmware
Data at Rest Encryption
(SEDs with local or external key mgmt)
Secure Boot
Secured Component Verification (Hardware integrity check)
Secure Erase
Silicon Root of Trust
System Lockdown
(requires iDRAC9 Enterprise or Datacenter)
TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China
Front ports
1 x iDRAC Direct (Micro-AB USB) port
1 x USB 2.0
1 x VGA
Rear ports
1 x USB 2.0
1 x USB 3.0
1 x VGA
1 x RJ45 iDRAC9 ethernet port
Canonical Ubuntu Server LTS
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
VMware ESXi
For specifications and interoperability details, see Dell.com/OSsupport.
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. For more information,
visit Dell.com > Solutions > OEM Solutions.
