Unmatched Performance for AI Excellence in a 4U liquid cooled chassis.
* Manufacturer’s Suggested Retail Price
Two 5th Generation Intel® Xeon® Scalable Processors with up to 64 cores per processor
32 DDR5 DIMM slots, supports RDIMM 4 TB max, speeds up to 5600 MT/s
Note: Supports registered ECC DDR5 DIMMs only
Internal Boot: Boot Optimized Storage Subsystem (NVMe BOSS-N1): HWRAID 1, 2 x M.2 SSDs
8 x NVIDIA HGX B200 180GB 1000W SXM6 GPUs, fully interconnected with NVIDIA NVLink technology
8 x NVIDIA HGX H200 141GB 700W SXM5 GPUs, fully interconnected with NVIDIA NVLink technology
IR5000 required
Up to 8 x 2.5-inch NVMe SSD drives max 122.88 TB
3000W Titanium 200-240 VAC or 240 VDC, hot swap redundant for B200 GPU
2800W Titanium 200-240 VAC or 240 VDC, hot swap redundant for H200 GPU
Liquid cooled CPUs, GPUs, and NVLink Switches
Intel® C741 chipset
Up to 12 x16 Gen5 (x16 PCIe) full-height, half-length slots
2 x 1 GbE
1 x OCP 3.0 (x8 PCIe lanes)
Six high performance (HPR) gold grade fans installed on the top layer
Six high performance (HPR) gold grade fans installed on the bottom layer of the system
Height — 174.3 mm (6.86 inches)
Width — Upper 2U: 447 mm (17.59 inches)
— Lower 2U: 434 mm (17.08 inches)
Depth — 1037.57 mm (40.82 inches) with bezel
— 1025.62 mm (40.37 inches) without bezel
Weight — 95.60 kg ( 206.35 pounds)
4U rack server
iDRAC9
iDRAC Direct
iDRAC RESTful API with Redfish
iDRAC Service Manual
Optional LCD bezel or security bezel
CloudIQ for PowerEdge plug in
OpenManage Enterprise
OpenManage Service plugin
OpenManage Power Manager plugin
OpenManage Update Manager plugin
BMC Truesight
OpenManage Integration with ServiceNow
Red Hat Ansible Modules
Terraform Providers
Cryptographically signed firmware
Data at Rest Encryption
(SEDs with local or external key mgmt)
Secure Boot
Secured Component Verification
(Hardware integrity check)
Secure Erase
Silicon Root of Trust
System Lockdown
(requires iDRAC9 Enterprise or Datacenter)
TPM 2.0 FIPS, CC-TCG certified
Front ports
1 x iDRAC Direct (Micro-AB USB) port
1 x USB 2.0
1 x VGA
Rear ports
1 x USB 2.0
1 x USB 3.0
1 x iDRAC Direct ethernet port
Canonical Ubuntu Server LTS
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. For more information,
visit Dell.com > Solutions > OEM Solutions
