Ruckus ICX 7750-48F – switch – 48 ports – managed – rack-mountable

(ICX7750-48F)

Categories: , , ,

The Ruckus ICX 7750 delivers chassis performance in the network’s aggregation and core switching operations. The switch’s premier speed and reliability in a flexible scale-out design enables a small deployment to add capacity as needs grow and deliver mission-critical application services with complete confidence. The ICX 7750 provides the capabilities of a chassis with the flexibility and cost-effectiveness of a stackable switch. The switch delivers faster network response time via wire-speed, non-blocking performance across all ports to support latency-sensitive applications such as real-time voice or video streaming and Virtual Desktop Infrastructure. Up to 12 ICX 7750 switches can be stacked together to provide terabytes of aggregated stacking bandwidth with full redundancy, eliminating inter-switch bottlenecks.

Product Specifications

ManufacturerRuckus Wireless
BrandRuckus
Product LineRuckus ICX
Model7750-48F
Packaged Quantity1

PerformancePort-to-port latency: 550 ns, Switching capacity: 1.92 Tbps, Throughput: 1.44 Bpps

CapacityACL entries: 4000, IGMP groups: 8192, IP hosts: 131072, IPv4 routes: 131072, IPv6 routes: 7168, Maximum aggregation groups: 128, Maximum frame size: 10220, QoS hardware queues per port: 8, Rapid Spanning Tree Protocol instances: 254, Spanning Tree Protocol instances: 16, Virtual interfaces (VLANs): 4095, Virtual Routing and Forwarding (VRF) entries: 64

TypeSwitch
SubcategoryNetwork hubs and switches
Subtype10 Gigabit Ethernet
Form FactorRack-mountable
StackableStackable
Ports Qty48
Advanced SwitchingLayer 3
Routing ProtocolRIP-1, RIP-2, Static IP routing, VRRP
MAC Address Table Size294912 entries
Jumbo Frame SupportYes
ManageableYes
Remote Management ProtocolCLI, RMON, SNMP 1, SNMP 2, SNMP 3, SSH-2, Telnet, TFTP
Features12.2MB packet buffer, Access Control List (ACL) support, ARP support, BOOTP support, DDos attack prevention, DHCP support, Flow control, IGMP proxy, IPv4 support, IPv6 support, Link Aggregation Control Protocol (LACP), LLDP support, MAC address filtering, Management Information Base (MIB), Metro Ring Protocol (MRP) support, MRP-II support, Multiple Spanning Tree Protocol (MSTP) support, Per-VLAN Spanning Tree (PVST), PIM snooping, Port based access control, Port mirroring, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, RARP support, sFlow, SNTP support, Spanning Tree Protocol (STP) support, STP PortFast, STP Root Guard, Strict Priority (SP), Tagged VLAN, Type of Service (ToS), Virtual Routing and Forwarding (VRF), Virtual Switch Redundancy Protocol (VSRP) support, VLAN support, Weighted Round Robin (WRR) queuing
Compliant StandardsIEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Qty48
Type1 Gigabit / 10 Gigabit SFP+
Qty6
Type40 Gigabit QSFP+

Expansion Slots1 (total) / 1 (free) x expansion slot

Interfaces1 x 1000Base-T RJ-45 management, 1 x mini-USB management, 48 x Gigabit / 10Gbit LAN SFP+, 6 x 40Gbit LAN QSFP+ (breakout compatible)

TypeInternal power supply, Internal power supply (not installed)
Hot-PlugHot-plug
Power RedundancyOptional
Power Redundancy Scheme1+1 (with optional power supply)
Installed Qty0
Max Supported Qty2
Power Consumption Operational269 watt

OS RequiredHP-UX, IBM AIX, Microsoft Windows NT, SunSoft Solaris

Height (Rack Units)1
Encryption AlgorithmAES, MD5
Authentication MethodRADIUS, Secure Shell v.2 (SSH2), TACACS, TACACS+
Compliant StandardsCAN/CSA C22.2 No. 60950-1-07, CISPR 22 Class A, EN 60825-1, EN 60825-2, EN 60950-1:2006, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-1, EN 61000-6-3, EN55022 Class A, EN55024, FCC Part 15 A, ICES-003, IEC 60950-1 Second Edition, RoHS 6/6, UL 60950-1 Second Edition, VCCI Class A, WEEE
Width17.3 inch
Depth16 inch
Height1.7 inch
Weight20.02 lbs

TypeLimited lifetime warranty

Service & SupportLimited warranty – lifetime

Min Operating Temperature32 degree Fahrenheit
Max Operating Temperature113 degree Fahrenheit
Min Storage Temperature-13 degree Fahrenheit
Max Storage Temperature158 degree Fahrenheit
Humidity Range Operating5 – 95% (non-condensing)
Humidity Range Storage5 – 80% (non-condensing)
