Ruckus R750 – wireless access point

(9F1-R750-US00)

Categories: Networking, Ruckus, R750, Wireless Access Points, R Series

The R750 is based on Wi-Fi 6 standard and bridges the performance gap from Gigabit Wi-Fi to multi-Gigabit Wi-Fi in support of the insatiable demand for better and faster Wi-Fi. The R750 makes it easy to deliver reliable, secure, high-performance connectivity in transit hubs, auditoriums, conference centers and other high traffic indoor spaces.

Main Features

Wireless access point
802.11ax
Wi-Fi
2.4 GHz
5 GHz

Call for Pricing

Product Specifications

Header

ManufacturerRuckus Wireless

BrandRuckus

Product LineRuckus

ModelR750

Country KitsUnited States

Packaged Quantity1

Antenna

Antenna Form FactorInternal

Gain Level3 DBi

Chassis

Ruggedized DesignIndoor

Line Properties

Line Coding FormatOFDM

Performance

PerformanceMaximum data rate (2.4 GHz): 1148 Mbps, Maximum data rate (5 GHz): 2400 Mbps

Capacity

CapacityAntenna patterns (per band): 4000+, Concurrent users: 1024, Rx sensitivity (2.4 / 5GHz): -102dBm, SSIDs per radio: 31

Networking

TypeWireless access point

Form FactorExternal

Connectivity TechnologyWireless

Data Link ProtocolIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Wireless Protocol802.11a/b/g/n/ac/ax

Cloud-ManagedYes

Wi-Fi Bands2.4 GHz, 5 GHz

Power Over Ethernet (PoE)PoE+

Features4×4 MU-MIMO technology, 4×4 SU-MIMO technology, 4×4:4 streams, Auto-sensing per device, Auto-uplink (auto MDI/MDI-X), Backhaul Technology, BeamFlex+ Smart Antenna Technology, Bluetooth (BLE) clients support, Ceiling mountable, ChannelFly, Cloud managed, DHCP support, IPv4 support, IPv6 support, Link Aggregation Control Protocol (LACP), Manageable, Maximum Ratio Combining (MRC), NAT support, Quality of Service (QoS), Security lock slot (cable lock sold separately), SmartMesh, Space Time Blocking Code (STBC), VLAN support, Wall mountable, Wi-Fi Multimedia (WMM) support

Compliant StandardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, Wi-Fi CERTIFIED 6

Encryption AlgorithmAES, Opportunistic Wireless Encryption (OWE), TKIP, WPA2, WPA3, WPA-PSK

Authentication MethodBasic Service Set Identifier (BSSID), RADIUS

Compliant StandardsEN 50121-1, EN 50121-4, EN 60601-1-2, EN 60950-1, EN 61000-4-2, EN 61000-4-3, EN 61000-4-5, EN 62311, IEC 61373, ISTA 2A, RoHS, UL 2043, WEEE

Dimensions & Weight

Width8.1 inch

Depth9.3 inch

Height2.4 inch

Weight2.23 lbs

Environmental Parameters

Min Operating Temperature32 degree Fahrenheit

Max Operating Temperature122 degree Fahrenheit

Humidity Range Operating0 – 95% (non-condensing)
