Home » Products » Servers » Supermicro SuperServer 5019P-WTR – rack-mountable no CPU – 0 GB – no HDD

Supermicro SuperServer 5019P-WTR – rack-mountable no CPU – 0 GB – no HDD

(SYS-5019P-WTR)

Categories: Servers, SuperMicro, Rack Servers

Supermicro provides the outstanding product line, their proven high level of quality and performance has made SuperServers the platform of choice for enterprise, cloud, data center, hyperscale, embedded, and business-critical, front-end server applications.

Quick tech specs

WTR
rack-mountable 1U
no CPU up to
SATA
no HDD
Gigabit Ethernet, 10 Gigabit Ethernet
monitor: none
Server
1-way
RAM 0 GB
hot-swap 3.5″ bay(s)
AST2500
no OS
black

Product Specifications

BrandSupermicro

Product LineSupermicro SuperServer

Model5019P-WTR

ManufacturerSuper Micro Computer Inc

Processor SocketSocket P

Processor TypeNo CPU

Server Scalability1-way

Total Processor Supported1

UpgradabilityUpgradable

Available Memory Slots6

Data Integrity CheckECC

Features3DS Load-Reduced DIMM (LRDIMM), Registered

Max Memory Supported768 GB

Memory Slots6

Memory Supported192 GB registered – ECC, 768 GB 3DS Load-Reduced – ECC

Memory TechnologyDDR4 SDRAM

RAM Installed0 GB

Channel Quantity10

Drive TypeNo optical drive

Optical Drive TypeNo optical drive, None

Optical Drive Type (2nd)None

RAID LevelsRAID 0, RAID 1, RAID 10, RAID 5

Storage (2nd)None

Storage (3rd)None

Storage (4th)None

Storage Controller TypeSerial ATA

TypeNone

Hard Drive Interface TypeNo HDD

Data Link Protocols10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet

Ethernet ControllersIntel X772, X557

Ethernet Ports2 x 10 Gigabit Ethernet

FeaturesACPI support, KVM over IP support

Remote ManagementIPMI 2.0

Expansion Bays4 (total) / 4 (free) x hot-swap 3.5″

Slots1 (total) / 1 (free) x CPU, 1 (total) / 1 (free) x M.2 Card, 1 (total) / 1 (free) x PCIe 3.0 x8 – low-profile, 2 (total) / 2 (free) x PCIe 3.0 x16 – full-length, full-height, 6 (total) / 6 (free) x DIMM 288-pin

Interface Provided1 x management – RJ-45, 1 x serial, 1 x VGA, 2 x LAN (10Gigabit Ethernet), 2 x USB 2.0, 2 x USB 3.0

Display TechnologyNone.

Graphics Controller ModelASPEED AST2500

Graphics Processor SeriesASPEED AST

Video InterfacesVGA

Audio Input TypeNone

Frequency50 – 60 hertz

Power Device TypePower supply

Power Provided500 watt

Power Supplies Installed2

Power Supplies Supported2

Redundant Power SupplyYes

Redundant Power Supply Supported1+1

80 PLUS Certification80 PLUS Platinum

Operating System EditionNo operating system

Chipset TypeIntel C622

Form FactorRack-mountable

Form Factor (RAM)DIMM 288-pin

Storage Controller InterfaceSerial ATA-600

Max Operating Temperature95 degree Fahrenheit

Min Operating Temperature50 degree Fahrenheit

Operating Humidity8 – 90% (non-condensing)

Controllers Included1

Printer Product TypeNone

Hot-Swap Bays4

Manufacturer Form FactorRack-mountable

Packaged Quantity1

Product TypeServer

Server Storage BaysHot-swap

Server Swappable Drive Form Factor3.5″

Server Swappable Drive Form Factor (metric)8.9 cm

Server Swappable Drive InterfaceSATA

CablesSerial ATA cable (4 pcs.), SGPIO cable

Included Accessories2 x riser cards, CPU Heatsink

Height1.7 inch

Height (Rack Units)1

Weight24.01 lbs

Width17.2 inch

Depth25.6 inch

ColorBlack

Color CategoryBlack

Compliant StandardsRoHS

TCO CertifiedNo

Service & Support DetailsLimited warranty – labor – 3 years, Limited warranty – parts – 1 year

Limited Warranty3 Year
