Supermicro SuperServer E300-9D-8CN8TP – Mini-ITX Box PC – Xeon D-2146NT – 0 GB – no HDD

(SYS-E300-9D-8CN8TP)

Categories: Servers, SuperMicro, Rack Servers

Supermicro provides the outstanding product line, their proven high level of quality and performance has made SuperServers the platform of choice for enterprise, cloud, data center, hyperscale, embedded, and business-critical, front-end server applications.

Quick Tech Specs

9D-8CN8TP
Mini-ITX Box PC
1-way
RAM 0 GB
AST2500
no OS
black
Server
1U
1 x Xeon D-2146NT up to
no HDD
Gigabit Ethernet, 10 Gigabit Ethernet
monitor: none

Product Specifications

BrandSupermicro

Product LineSupermicro SuperServer

ModelE300-9D-8CN8TP

ManufacturerSuper Micro Computer Inc

Cores8-core

Processor BrandIntel

Processor NumberD-2146NT

Processor TypeXeon

Processors Installed1

Server Scalability1-way

Total Processor Supported1

Available Memory Slots4

FeaturesLoad-Reduced DIMM (LRDIMM), Registered

Max Memory Supported512 GB

Memory Slots4

Memory Supported256 GB registered – ECC, 256 GB registered – non-ECC, 512 GB Load-Reduced – ECC

Memory TechnologyDDR4 SDRAM

RAM Installed0 GB

Channel Quantity4

Drive TypeNo optical drive

Optical Drive TypeNo optical drive, None

Optical Drive Type (2nd)None

RAID LevelsRAID 0, RAID 1, RAID 10, RAID 5

Storage (2nd)None

Storage (3rd)None

Storage (4th)None

Storage Controller (2nd)NVM Express

Storage Controller TypeRAID

TypeNone

Hard Drive Interface TypeNo HD

Data Link Protocols10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet

Ethernet Ports2 x 10 Gigabit Ethernet, 4 x Gigabit Ethernet, 2 x SFP+

FeaturesKVM over IP support

Remote ManagementIPMI 2.0

Expansion Bays1 (total) / 1 (free) x internal 2.5″

Slots1 (total) / 1 (free) x M.2 Card – 2242/2280 (Key M), 1 (total) / 1 (free) x M.2 Card (Key B), 1 (total) / 1 (free) x Mini PCIe/mSATA, 1 (total) / 1 (free) x PCIe 3.0 x8

Interface Provided1 x management – RJ-45, 1 x VGA, 2 x LAN (10Gigabit Ethernet) – RJ-45, 2 x LAN (10Gigabit Ethernet) (SFP+), 2 x USB 3.0, 4 x LAN (Gigabit Ethernet) – RJ-45

Display TechnologyNone.

Graphics Controller ModelASPEED AST2500

Graphics Processor SeriesASPEED AST

Video InterfacesVGA

Audio Input TypeNone

Power Device TypePower adapter

Power Factor Correction (PFC)Yes

Power Provided150 watt

Operating System EditionNo operating system

Form FactorUltra Small Form Factor

Form Factor (RAM)DIMM 288-pin

Storage Controller InterfaceSerial ATA-600
