High Capacity and Peak Computing Performance for Memory-Intensive Applications
• Performance increase of up to 50% compared to the previous generation of Intel processors
• Unprecedented CPU computing performance with low latencies
• Quad high-performance Intel® Xeon® 6700 series processors with P-cores for a total of up to 344 cores
• Up to 64 DIMM slots supporting DDR5-6400MT/s
• Supports up to 6 double-width GPUs for enterprise AI workloads
• High-efficiency Titanium Level power supplies to further minimize total cost of ownership (TCO) and environmental impact
* Manufacturer’s Suggested Retail Price
4U Rackmount 438.4 x 177 x 848.7mm (17.3” x 7” x 33.4”)
X14QBH+
Quad Intel® Xeon® 6700 series processors with P-cores Up to 350W TDP (air cooled)
64 DIMM slots
Up to 8TB DDR5-6400MT/s (1DPC)
Up to 16TB DDR5-5200MT/s (2DPC)
Default
4 PCIe 5.0 x8 FHHL slots
2 PCIe 5.0 x16 FHHL slots
8 PCIe 5.0 x8 FHFL slots
4 PCIe 5.0 x16 FHFL slots
2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)
Option A
6 PCIe 5.0 x16 FHFL double-width slots
2 PCIe 5.0 x16 FHHL slots
4 PCIe 5.0 x8 FHHL slots
2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)
Up to 6 double-width GPUs
24 hot-swap 2.5” NVMe/SAS/SATA drive bays
1 M.2 PCIe 4.0 x4 NVMe M-key (2280/22110) slot
1 M.2 PCIe 4.0 x4 NVMe M-key (22110) slot
10 heavy duty counter-rotating 8cm fans
4 redundant 2700W Titanium Level power supplies
