HPE ProLiant DL360 Gen10 – rack-mountable – Xeon Silver 4208 2.1 GHz – 16 G

(6424482)

Categories: Servers, HP ProLiant, Rackmount Servers, DL360 Gen10

Does your data center need a secure, performance driven dense server that you can confidently deploy for virtualization, database, or high-performance computing? The HPE ProLiant DL360 Gen10 server delivers security, agility and flexibility without compromise.

Product Specifications

Chassis Form Factor :Rack-mountable Manufacturer Form Factor :Rack-mountable Server Storage Bays :Hot-swap Server Swappable Drive Form Factor :3.5″ Server Swappable Drive Form Factor (metric) :8.9 cm Server Swappable Drive Interface :SATA Hot-Swap Bays Qty :4 Built-in Devices :LED panel Processor Type :Xeon Silver Number of Cores :8-core Processor Number :4208 Installed Qty :1 Max Supported Qty :2 Server Scalability :2-way Upgradability :Upgradable Manufacturer :Intel Clock Speed :2.1 GHZ Max Turbo Speed :3.2 GHZ Processor Main Features :Hyper-Threading Technology, Intel Turbo Boost Technology 2

Cache Memory Type :L3 cache Installed Size :11 megabyte RAM Form Factor :DIMM 288-pin Technology :DDR4 SDRAM Installed Size :16 GB Max Supported Size :1.5 TB Configuration Features :1 x 16 GB Data Integrity Check :Advanced ECC Slots Qty :24 Empty Slots :23 Memory Speed :2400 megahertz Rated Memory Speed :2933 megahertz Features :Dual rank, HPE SmartMemory, Registered, Slots 13 – 24 are available in two-processor configuration only RAM Supported RAM Supported :1.5 TB registered – ECC, 192 GB Non-Volatile – ECC, 3 TB Load-Reduced – ECC

Type :Serial ATA Interface Type :Serial ATA-600 Storage Controller Name :HPE Smart Array S100i SR Software Channel Qty :14 Installed Qty :1

Networking Ethernet Controller(s) :HPE 366FLR Remote Management Controller :Integrated Lights-Out 5 Data Link Protocol :Ethernet, Fast Ethernet, Gigabit Ethernet Ethernet Ports :4 x Gigabit Ethernet Remote Management Protocol :IPMI 2.0, SMASH CLP, SNMP 3 Features :PXE support, Wake on LAN (WoL) Expansion Bays Bays :1 (total) / 1 (free) x external Universal Media Bay, 4 (total) / 4 (free) x hot-swap 3.5″ LFF Expansion Slots Slots :1 (total) / 1 (free) x FlexibleLOM – three-quarter-length, full-height (low-profile), 1 (total) / 1 (free) x microSD Card (internal), 1 (total) / 1 (free) x PCIe 3.0 x16 – three-quarter-length, full-height, 1 (total) / 1 (free) x PCIe 3.0 x8 – low-profile, 1 (total) / 1 (free) x PCIe x16 – full-height Interface Provided Interfaces :1 x HPE iLO – RJ-45 (1 rear), 1 x HPE iLO – Type A (1 in front), 1 x VGA (1 rear), 4 x LAN (Gigabit Ethernet) – RJ-45 (4 rear), 5 x USB 3.0 (1 front, 2 rear, 2 internal)

Power Device Type :Power supply – hot-plug Power Redundancy :Optional Power Redundancy Scheme :1+1 (with optional power supply) Installed Qty :1 Max Supported Qty :2 Power Provided :500 watt Nominal Voltage :AC 120/230 V Frequency Required :50/60 hertz 80 PLUS Certification :80 PLUS Platinum

Service & Support Details Service & Support :Limited warranty – parts and labor – 3 years – on-site
